Leica DD120 Utility Locator dual frequency with depth

Leica DD120 Utility Locator dual frequency with depth


BRAND: Leica

Price ex VAT

The Leica DD100 Series cable locators feature advanced automatic controls making the DD100 Series easy-to-use, requiring minimal user experience.

Avoiding underground cables and pipes is a major concern on construction sites. Therefore, detecting the position of buried cables and pipes before excavation work can help prevent operator injury, asset damage and any subsequent costs.

With Automatic Pinpointing there is no need for you to manually adjust the sensitivity of your cable locator ensuring you’re using the optimum sensitivity for the environment you are detecting the underground utilities in - Reducing the likelihood of human error and enabling easier and more efficient cable and pipe locating. Ultimately saving you time and money.

Use the DD120 or DD130 cable locators in conjunction with a DA220 or A230 signal transmitter or range of accessories to achieve improved accuracy and application scope.

DD120 Features
  • Automatic pinpointing
  • Power, radio, auto modes
  • Transmitter, 33 kHz, 8 kHz
  • Depth detection up to 3 metres (10 feet)
  • Good-to-Go™ health check and start up test
  • IP54 rating - protection from dust and water
  • 1-year warranty
MODE DD120 DD130
Power 50Hz model or 60Hz model 50Hz model or 60Hz model
Radio 15kHz to 60kHz 15kHz to 60kHz
Auto Power, Radio, 33kHz Power, Radio, 33kHz
Transmitter Modes 32.768 (33) kHz
8.192 (8) kHz
32.768 (33) kHz
8.192 (8) kHz
512 Hz
640 Hz
Depth Range Line 0.3m to 3m / 1ft to 10 ft
Sonde 0.3m to 3m / 1ft to 10 ft
Line 0.3m to 3m / 1ft to 10ft
Sonde 0.3m to 9.99m / 1 ft to 32.77 ft
Depth Accuracy* 10% 10%
Environmental Standard IP54 IP54
Operating Temperature -20° C to +50° C
-4° F to +122° F
-20° C to +50° C
-4° F to +122° F
Battery 6 x LR6 (AA) Alkaline 6 x LR6 (AA) Alkaline
Battery operating time** 15 h 15 h
Dimensions (HxWxD) 760 x 250 y 85mm
(30 x 10 x 3.4 inches)
760 x 250 y 85mm
(30 x 10 x 3.4 inches)
Weight with batteries 2.7Kg
5.95 lbs
5.95 lbs
* Depth to an undistorted signal
** Constant use at 20°C/68°F

All images ©2018 Leica Limited

Subtech Safety Limited are official Distributers for Leica Limited products
